X8L Tiltrotor eVTOL Platform
Compact in size, giant in mission
X8L Basic Numbers
1000 mm
dimension
60 km/h
cruise speed
60 min
duration
3500
g
take-off weight
The X8L is a lightweight electric VTOL fixed-wing drone with a 1 m wingspan and 3.5 kg MTOW. Its fully integrated tilt-rotor system combines propulsion, tilt mechanism, variable-pitch propellers, and control surfaces in a compact wingtip module, enabling seamless mode transition and efficient flight.
Design
Something Different
Tiltrotor Vertical
Takeoff and Landing
The tilt system adjusts motor thrust direction for smooth transition between multicopter VTOL and fixed-wing cruise. Unlike conventional differential thrust control, X8L achieves vector control through tilt, offering faster response and stronger wind resistance.
Efficiency
Variable-Pitch System
The variable-pitch system automatically adjusts blade angle according to flight mode, maximizing aerodynamic efficiency, reducing noise, and ensuring optimal hover and cruise performance.
Portable
Tandem-Wing Layout
The tandem-wing layout shortens wingspan while preserving lift and payload capacity. Compact, easy to transport and operate, yet capable of up to 60 minutes of stable cruise.
Manufacturing
Quality and cost
The X8L is built to be lightweight, strong, and easy to maintain. Its main structure uses carbon fiber composites formed under heat and pressure. This keeps the airframe stable and aerodynamic at high speeds.
Critical high-load drive components
including the tilt mechanism, servo transmission system, and variable-pitch assembly, are CNC-machined from aerospace-grade aluminum to deliver excellent precision, mechanical consistency, and long-term durability.
Other non-structural parts
using industrial 3D printing and injection molding to reduce weight and cost. The modular design allows for quick assembly, easy maintenance, and fast part replacement in the field.
Technical Specification
Wingspan
1000 mm
Length
1000 mm
Max Take-off Weight
3500g
Max Payload Weight
300g
Cruise Speed
60 km/h
Duration
60 min
Range
60 km
Wind Resistance
10 m/s
Material
Composite
Transport case dimension
810 x 280 x 220 mm
Battery Capacity
8300 - 8500mAh
Operating Temperature
0 - 40 °C
Communication Range
10 - 30 km
Deployment Time
5 mins
